Omron

Timer H3CR-A-302 DC24 Omron

BrandOmron
Item codeH3CR-A-302 DC24
Commitment100% genuine products
PolicyCatalog Omron H3CR Series
Description- Wide AC/DC power supply range significantly reduces the number of timer patterns stored. - Wide range of applications and multiple operating modes, eight modes for the 11-pin model and five modes for the 8-pin model. - Environmentally friendly design with reduced current consumption. - Easy sequence testing with instantaneous outputs for zero set value. - Length of 75 mm or less when panel mounted with P3G-08 socket (H3CR-A8E, 100 to 240 VAC, 100 to 125 VDC). - PNP input models available. - Standards: UL, CSA, NK, LR, CCC, EN 61812-1 and CE.

REQUEST A QUOTE

Technical information
Type Screw type
Function On Delay, Flicker Off Start, Flicker On Start, On/Off Delay, Off Delay, Interval, One-shot
Time 0.05s-300h
Supply voltage 24VDC
Signal input Voltage-free input
Control output 1 2 Relay NO/NC
Connection type 11 pin socket
Accessories (purchased separately) P2CF-11, P2CF-11-E, P3GA-11
Weight 90g
