Technical information
| Power | 480 W |
|---|---|
| Electrical voltage input | 400-500 VAC |
| Range electrical voltage input | 340-576 VAC/480-810 VDC |
| Frequency number | 50-60 Hz |
| Number pha | 3 pha |
| Electrical voltage output | 24 V |
| Current rated output | 20A |
| Signal power | 0.91 |
| Range control adjustment electrical voltage output | 21.6-28.0 VDC |
| Current leakage | less than 3.5mA |
| System number power | 0.86 |
| Time start operation output | 1.3s |
| Time retaining output | 15 ms |
| Indicator indicator output | LED green blade |
| Method solution work cooling | Work cooling automatic however |
| Function capacity | Short-circuit protection, overload, over voltage |
| Service life | 10 year |
| Ambient temperature | -10-70°C |
| Humidity environment | 10-90%RH |
| Weight quantity | 1.8kg |
